PROFILDECK® Aluminium Joist H55
Profildeck Decking Board Screw
Reference:
IPDVISLAMC10000
Compatible
Terraces
Timber decking
Hybrid terraces
Riser pedestal terraces
Joist support riser pedestals
Accessories
PROFILDECK joists
Our products in detail
Description
These 5.5 x 45 mm self-tapping screws are used to fix timber decking boards to the PROFILDECK® joist. Countersunk Torx screw. Bit: SIT20.
Made in France.
10 year warranty
Iso9001
Iso14001
label MORE.
Information sorting
Keypoints
Self-tapping screws for use with aluminium joists.
Quick and easy to use.
Documentation
Technical data sheet
PDF - 723 KB
Profildeck decking board screw
Directions for use
PDF - 5 MB
Wooden terrace H27
Directions for use
PDF - 7 MB
Wooden terrace H55
Directions for use
PDF - 5 MB
Hybrid timber and paved terrace H27
Directions for use
PDF - 5 MB
PROFILDECK® Hybrid timber and paved terrace H55
Technical characteristics
Length in mm:
45
Color:
Grey
Material:
A4 Stainless steel
Weight KG:
0,0052kg
Packing:
Box of 50 parts
Installation and Application
Max torque rating: 7Nm max (position “18” on an 18V cordless combi drill). Terraces for pedestrian and outdoor use only.
a question?
Our landscaping experts have the answers
1. What are Profildeck® decking screws used for?
Profildeck® decking screws are specially designed to fix timber decking boards to Profildeck® system aluminium joists. Their self-tapping design ensures firm fixing with no need for pre-drilling. Manufactured from A4 stainless steel, they deliver excellent levels of weather and corrosion resistance.
2. How are Profildeck® decking screws used?
Once the deck boards have been laid in accordance with French building regulation DTU 51.4., Profildeck® screws are screwed directly through the decking board and into the aluminium joist, using a maximum torque rating of 7 Nm (position “18” on a 20-position 18V cordless combi drill). It is important to check that the screws are compatible with the material used, particularly in the case of composite decking boards, which may require specific fixing methods.
