ALVEPLAC Gravel Stabilisation Double Mat Grey

Reference: IHALV030DP40000
ALVEPLAC-DOUBLE-GRIS-PICT-PS-3
ALVEPLAC-GENERAL-PICT-GAL3-7
ALVEPLAC-GRIS-PICT-GAL2-5
ALVEPLAC-GRIS-PICT-GAL1-5
Compatible Driveways and parking spaces Pavers Stabilisation modules Aggregate modules
Color :
Grey White
Reset declinations
Aggregate stabilisation module with integral geotextile membrane.
Stabilises aggregate surfaces.
For private, public, community, commercial or industrial use.

Configure a project
Find a dealer
Our products in detail

Description

alveplac-double-zoom-1-1

60G/m² geotextile membrane permanently bonded to the honeycomb cells by the exclusive Jouplast® welding process used during the injection moulding phase.

alveplac-double-zoom-2-1

Integral interlocking assembly system to ensure maximum stability of adjoining modules.

alveplac-double-zoom-3-1

Keeps aggregate in place

Gravel stabilisation tile with integrated geotextile membrane for use in landscaping projects. Ideal for creating walkways, garden paths, car parking areas, paths and driveways for private, public, commercial or industrial use. Creates a perfect finish, because the tile becomes invisible when filled.

Made-in-France-1 Made in France.
Warranty 10 years 10 year warranty
ISO-9001-1 Iso9001
iso-14001-1 Iso14001
more-2024-1 label MORE.
Info-tri-1 Information sorting
recycle-1 Recycled material.

Keypoints

doigt Keeps aggregate in place.
picto_Evacuation-eau-1 Rapid surface water infiltration.
picto_Goutte-barree-1 Prevents puddling and rutting.
picto_Chrono-1 Quick and easy to install.
ALVEPLAC-GENERAL-INSPI-5

Documentation

Technical data sheet

PDF - 1 MB
ALVEPLAC gravel stabilisation double mat grey
Open

Directions for use

PDF - 4 MB
Alveplac - urban areas
Open

Directions for use

PDF - 4 MB
Alveplac - landscaping areas
Open

Technical characteristics

Length in mm:
1166
Width in mm:
1600
Thickness in mm:
30
Material:
Recycled polypropylene
Color:
Grey
Usable area in SQM:
1,817m2
Weight KG:
3,4kg
Stackable:
Yes
Packing:
Pallet of 19 parts

Installation and Application

Alveplac® is guaranteed effective once the modules have been filled with aggregate, plus an additional 2 cm top layer. Fill using 5/15 or 8/16 driveable aggregate.

In addition to poser on your terrace...

Jouplast experts offer you the products you need for your terrace project.

a question?

Our landscaping experts have the answers

1. Is it essential to use aggregate stabilisation modules?

The use of aggregate stabilisation modules is not essential, but it is strongly recommended for several reasons:

  • To prevent aggregate depression and spread: where no stabilisation is used, the aggregate can be depressed into the ground and spread.
  • To improve drainage: aggregate stabilisation often involves the use of a geotextile membrane to improve water soil infiltration, and therefore reduce the risk of puddling and erosion.
  • Visual appearance and maintenance: stabilisation modules hold aggregate in place, improving the visual appearance and making maintenance easier.
  • Durability and strength: aggregate stabilisation extends the durability of aggregate surfaces, as a result of its higher load-bearing capacity and resistance to extreme weather conditions.
