Acoustic Rubber Cushion for Essential Paving Riser Pedestal Box of 100 Parts
Isolation Mat for Riser Pedestal
Reference:
IHTAPISOL10000
Compatible
Terraces
Timber decking
Paved terrace
Riser pedestal terraces
Accessories
Our products in detail
Description
Provides extra thickness.
A material that reduces vibration, dampens transmitted impact noise and reduces any resonances.
This recycled natural rubber mat is designed to isolate the terrace riser pedestal from the substrate it stands on, thereby reducing structural vibration and impact noise. It also improves the overall stability of the structure.
Made in France.
10 year warranty
Iso9001
Iso14001
label MORE.
Information sorting
Recycled material.
Keypoints
Dimensionally stable, immovable and strong.
Improves stability.
Reduces structural vibration, dampens transmitted impact noise and reduces any resonances.
Quick and easy to fit.
Technical characteristics
Length in mm:
230
Width in mm:
225
Thickness in mm:
3
Color:
Black
Material:
Recycled tyre rubber
Weight KG:
0,125kg
Packing:
Box of 30 parts
Installation and Application
Do not use on aggregate surfaces. Terraces for pedestrian and outdoor use only.
Isolates the riser pedestal base from the underlying substrate. Also acts as a waterproof barrier.
a question?
Our landscaping experts have the answers
1. Why should the Jouplast® isolation mat be used?
The Jouplast® isolation mat is designed to isolate the terrace riser pedestal from the substrate it stands on. Dimensionally stable, immovable and strong, the mat adapts to irregularities in the foundations, thereby distributing loads more evenly. It also improves structural stability and helps reduce vibration, impact noise and resonances. It is particularly useful for improving acoustic comfort and increasing terrace durability.
2. How to use the Jouplast® isolation mat?
The Jouplast® isolation mat should be inserted between the terrace riser pedestals and the substrate (paved or other solid surface, for example). It can also be used on waterproofed substrates. It is simply inserted under the riser pedestal before terrace construction. Several mats can be laid on top of each other where the extra thickness is needed to adjust the height or provide a greater level of insolation. Please note that these mats are suitable for outdoor use only and should not be used on aggregate surfaces.
